MICRO ADJUST CABLES
Conwire manufacture a range of hand-operated control head cables. Typical
applications for these controls include: power take-offs, remote control
engine throttles, valves, chokes, shut-offs and various mechanical
linkages that require remote operation.
Micro Adjust Cables
Detachable with Friction Lock (Code L)
Detachable (Code M)
Micro Adjust control heads are ideal for remote operation of a
throttle, regulating valve, or other applications needing precise
adjustment capabilities. Depressing the center button allows
pushing or pulling the knob to make course travel adjustments.
A flexible dust seal protects the internal release mechanism.
Rotating the knob clockwise extends the output in the finite mode,
and counter-clockwise retracts. Four and one-half turns results
in 1 of linear travel. The maximum recommended load is 20lbs.
Normal vibration does not affect the micro adjust setting. An
optional friction lock accessory is available for applications where
vibration is excessive. A disconnect feature and various output end
configurations are available to suit a particular application. The
ordering code and technical description show these choices.
Non-Detachable (Code N)
Detachable with Friction Lock (Code K)
